Optimum characteristics for accurate temperature control available
High operating temperature (ASME 650 °C; DIN EN 600 °C)
Large allowable delta p water/steam pressure difference of up to 100 bar (1450 psi)
Excellent atomizing characteristics at a delta p water/steam of 5 bar (72.5 psi) and at steam
velocity of 10 m/s possible. The feld of application starts at steam velocities of 5 m/s and a rate of overheating to the saturation of 3°C. More favorable conditions will improve the effectiveness of the desuperheater
Excellent control accuracy for the wholecontrol range
Tight shut-off. No leakage in closed position and thus no emptying of the cooling water lines possible
No additional control valve required
High operation reliability. Due to simple parts, minimal wear
